Trade news

NOVOSENSE Launches Automotive-Grade High-Side Switches for Body Control Modules and Zone Control Units

　　NOVOSENSE Microelectronics, a semiconductor company specializing in high-performance analog and mixed-signal chips, has announced a range of high-side switches for driving traditional resistive, inductive, and halogen lamp loads in automotive body control modules (BCM) as well as large capacitive loads commonly found in the first-level and second-level power distribution within zone control units (ZCU).　　At time of launch, the NSE34 and NSE35 families includes 26 single-, dual- and quad-channel devices developed for operation across 11 separate load currents intervals (11 A to sub-2 A). These devices have an Rds(on) resistance range from 8 mΩ to 140 mΩ and feature industry-leading load-driving capabilities and advanced diagnostic and protection functions such as advanced over-current protection and over-voltage clamping protection.　　All devices in the two families are fully compliant with multiple automotive standards, including AEC-Q100, AEC-Q100-006, AEC-Q100-012 Grade A, ISO7637, ISO16570 and CISPR25-2021 Class 5.　　Yang WANG, Product Line Marketing Director of NOVOSENSE said: “For electric and autonomous vehicles, body domain controllers have become increasingly important, enabling smart power distribution and functional integration. Indeed, they are essential for many applications, whether in resistive loads such as a seat heater, capacitive or halogen lamp loads for surge-current handling, or inductive loads such as in wipers, solenoids and relays, where it protects against negative voltage spikes.”　　The NSE34 and NSE35 families of high-side switches are available in 14- and 16-pin HSSOP packages measuring 4.9mm x 3.9mm respectively.

Key word：

NOVOSENSE

Release time：2024-11-06 14:11 reading：1137 Continue reading>>

Trade news

A solution for automotive gear shift switch based on Hangshun chip automotive grade MCU HK32A040C8T3

　　Throughout the global development of passenger cars, automatic transmission has been widely adopted. Its simple and easy to learn, convenient and intelligent characteristics bring drivers a more comfortable driving experience, and also better adapt to urban traffic.　　The implementation of the automatic shift function actually uses a gear shift switch instead of manual operation. The gear shift switch will control the shift fork and gear shift based on different engine speeds, vehicle speeds, and the driver's intention to press the accelerator. To achieve these automated operations, a shift switch requires a brain.　　The Hangshun chip M0 series automotive grade MCU HK32A040C8T3 is such a "brain", applied in gear shift switch schemes. Its main function is to receive signals from the gear shift switch and convert these signals into electrical signals that can control the car's engine, transmission, and other parts, thereby simplifying driving operations and providing great convenience for the driver.　　In the process of developing its new generation of electric vehicles, in order to ensure that the vehicle's performance, reliability, and safety reach the optimal level, after in-depth technical evaluation and multiple rounds of screening, Selis New Energy Vehicles finally chose a gear shift switch scheme based on the Hangshun chip HK32A040C8T3.　　The Selis engineering team has conducted a rigorous review of the functional characteristics, processing speed, power consumption performance, environmental adaptability, and cost-effectiveness of the Hangshun HK32A040C8T3 MCU in multiple dimensions. Hangshun's MCU has successfully conquered the engineering team with its outstanding performance, especially in high reliability and strong anti-interference ability. In addition, HK32A040C8T3 has high integration and flexible peripheral interfaces, providing engineers with greater design freedom and optimization space, making the entire electronic control system more compact and efficient.　　HK32A040 using ARM ® Cortex ®- M0 core, with a maximum operating frequency of 96MHz, built-in up to 124 Kbyte Flash and 10 Kbyte SRAM. By configuring the Flash controller registers, the remapping of interrupt vectors within the main Flash area can be achieved. And it supports traditional Flash Level 0/1/2 read-write protection and Flash code encryption (patented by Hangshun).　　Strong scalability　　32-bit ARM CPU architecture, good ecological environment　　Rich peripheral resources to meet platform expansion　　Multiple packaging options available for LQFP64, LQFP48, QFN32, and QFN28　　high reliability　　Car specification quality, compliant with AEC-Q100 Grade 1　　Complies with ISO 9001 and IATFT 16949 quality management systems　　Supports -40 ℃~125 ℃　　High cost performance ratio　　Equal performance/resources, with higher cost-effectiveness　　Quality service　　Complete ecological supporting facilities　　15 years of design life, with a supply chain guarantee of over 15 years　　The gear shift switch scheme based on the Hangshun Vehicle Class MCU HK32A040C8T3 has been successfully applied in the Sailis new energy vehicle, which not only improves the electronic control efficiency of the entire vehicle, but also achieves lower energy consumption and better user experience.　　The Hangshun chip series vehicle grade MCU HK32A040 can be widely used in vehicle domain controllers, such as doors and windows, tail lights, wipers, anti-theft alarms, car keys, air conditioning, electric seats, etc.　　Hangshun Chip adheres to the strategy of SoC+32-bit high-end MCU in automotive standards. In recent years, it has invested a large amount of research and development resources in the field of automotive electronics, committed to providing the market with higher reliability and more cost-effective automotive chip solutions, helping customers achieve a win-win situation in cost control and user experience.

Key word：

Hangshun chip

Release time：2024-05-09 11:48 reading：1269 Continue reading>>

Trade news

Unlock New Possibilities with NXP NMH1000 Magnetic Switch

　　Sensors collect critical data from the environment which can be turned into useful insights in almost every industry. But they have varying capabilities, reliability and levels of innovation which ultimately determine the experiences they can deliver. Our recently launched NMH1000 Magnetic Switch is designed to meet today’s market needs. It is a rare breed of magnetic sensor that replaces traditional bulky mechanical switches which are unsuitable for difficult environmental conditions. The three reasons to consider NHM1000 for your development include its distinctive features, flexible application and ability to easily onboard.　　Distinctive Features of the NMH1000　　The NMH1000 is most sensitive to the magnetic fields that vertically pass through the top-to-bottom surfaces. Input consists of a magnetic field ranging in strength from earth-bound background, up to maximum BGMAX. Its input processing consists of functional blocks such as a configurable state machine, analog-to-voltage conversion of the input and comparison to generate the output, arranged in linear succession.　　The sensor detects the absence of a magnetic field and outputs either a high or low state upon comparison with preset thresholds. It operates down to 1.2V supply voltage, which ensures longer shelf life with ultra-low power consumption (75 nA typ. @ 1 Hz sample rate). And it comprises a small DFN package, making it easy to integrate in very small areas. The NMH1000 also supports two operation modes: the standalone mode and the I2C user mode. In the standalone mode, the sensor’s interface to its host is extremely simple, while the I2C provides a more sophisticated interface to extract additional functions.　　Use Cases for the NMH1000　　A key differentiator of the NMH1000 sensor is its flexibility. It can be used for medical, industrial, consumer and smart home applications. These include CGMs, continuous glucose monitoring, drug delivery devices such as a Smart Inhaler, electronic wake-up systems, gas and water flow applications, anti-tampering metering, reed switch replacement and alarm systems. The sensor can add new experiences to some of these applications. For example, the NHM1000 is handy in situations where smoke detectors are out of reach with no easy way to test their functionality. In this case, the sensor can be used with a telescoping magnet for testing from ground level. This can be done by positioning the magnet near the smoke detector to put it into test mode.　　Another interesting use case of the NMH1000 is laptop power control. In this use case, a magnet is on the laptop monitor and the NMH1000 is on the keyboard. When the lid comes down, the magnet is close to the NMH1000, so its output will change state. This notifies the controller to switch off the display and disable the keyboard. And when the lid is opened, the magnet disappears and the NHM1000 will change the state to the other direction, telling the system to turn on the display and the keyboard.　　Onboard Easily with NMH1000 Freedom Shield Evaluation Board　　We developed the NMH1000 Freedom Shield Evaluation Board to help our customers evaluate the NMH1000 and kickstart their development speedily. The board can be connected easily to an NXP Freedom MCU board via the Arduino headers for evaluation. It has all the necessary headers, jumpers and signal test points to quickly evaluate the NMH1000 magnetic sensor.　　Users can connect the two boards to evaluate the NMH1000 magnetic sensor. This is possible with either a terminal program using the NXP Component Library or a standalone mode use case. These evaluation boards provide an intuitive way to change between the sensor’s standalone modes and the I²C interface for communication through jumper selections. At the same time, they provide test points that are typically used for evaluation.

Key word：

NXP

Release time：2023-09-05 13:53 reading：2495 Continue reading>>

Trade news

NIDEC COMPONENTS DIP Slide Switch CVS

　　NIDEC COMPONENTS DIP Slide Switch CVS adopts compact design, 3bit product, knob handle height of 0.2mm, good operability of the terminals of 1mm spacing, the number of circuits is rich (2,3,4,8) terminal style is gull-wing, J-shaped leads are made of resin material UL certified 94V-0 RoHS compliant.　　NIDEC COMPONENTS DIP Slide Switch CVS Features: 1mm terminal spacing ultra-thin design, the upper height of the board 1.45mm electrical contact surface coating is gold.　　Product parameter　　Main use　　Commercial Air Conditioning (HVAC)　　elevator　　Other/General　　icebox　　LiDAR　　Other/General　　Other/General　　Other/General

Key word：

NIDEC COMPONENTS

Release time：2023-07-31 13:33 reading：3833 Continue reading>>

Trade news

AMEYA360:C&K Switches PTS381 Top-Actuated Tactile Switches

　　C&K Switches PTS381 Top-Actuated Tactile Switches are tact switches for wearable electronics, nomad devices, remote controls, and keyless entry system applications. The switches are momentary-action surface-mount (SMT) devices with silver-plated terminals. The series features a 160gf to 400gf operating force with up to 200,000 operations.　　FEATURES　　Non-shorting contact type　　SMT terminal type　　Ag-plated terminals　　Top-actuated operating direction　　Momentary action activation type　　160gf to 400gf operating force　　-40°C to +85°C operating temperature range　　Ratings　　12VDC, 50mA maximum　　1VDC, 10μA minimum　　Operating life with load　　200,000 cycles (160gf or 250gf operating force)　　100,000 cycles (400gF operating force)　　100mΩ maximum initial contact resistance　　APPLICATIONS　　Wearable electronics　　Nomad devices　　Remote controls　　Keyless entry system

Key word：

C&K Switches

Release time：2023-05-19 10:48 reading：1747 Continue reading>>

Trade news

Skyworks Solutions Inc. SI83004 & SI83014 Smart Switches

　　Skyworks Solutions Inc. SI83004 and SI83014 Smart Switches are designed to provide four high- or low-side switches with low RON. Skyworks Solutions Inc. SI83004 and SI83014 are excellent choices for driving resistive and inductive loads like solenoids, relays, and lamps commonly found in industrial control systems like Programmable Logic Controllers (PLC). The versatile switches can be interfaced directly with an MCU or controlled through a digital isolator or optocoupler-based isolation barrier. The devices have a logic interface that supports low-power 2.5V to 5V MCUs and is powered by the switch's high-voltage field power supply.　　FEATURES　　High-side or low-side switch　　9V–32V switch supply　　Fast (10s) update rate　　High continuous current (700mA) and low RON (150mΩ)　　Unique multi-voltage output clamp　　Unlimited demagnetization (EAS)　　Efficient and fast turn-OFF　　Current-limited overload protection　　Over temperature protection　　Undervoltage protection　　Three different diagnostics　　Overvoltage　　Over temperature　　Overcurrent　　Dedicated fault indicator　　Dedicated output enable input　　Designed to IEC 61131-2　　Compact TSSOP-24 package　　3.5kV ESD Protection　　–40°C to 125°C operating temperature　　APPLICATIONS　　Programmable logic controllers　　Industrial data acquisition　　Motion controllers　　Smart solid-state relays

Key word：

Skyworks,AMEYA360

Release time：2023-04-12 11:26 reading：1653 Continue reading>>

Trade news

AMEYA360:E-Switch KAD Multiple Position DIP Switches

　　E-Switch KAD Multiple Position DIP Switches have a tri-state feature that offers many code options over binary DIP switches. Making this switch even more versatile, multiple positions, 4, 5, 8, 9, or 10, with either straight pin (through-hole) or gullwing (SMT) termination, are available. KAD Switches have an electrical rating of 100mA@50VDC (non-switching), 25mA@24VDC (switching) with SPDT contact arrangements for each position, and a 2000 cycle rating for each circuit. Switches are supplied with all poles in the “OFF” position. The KAD DIP series provides a profile of 3.70mm (H) x 7.00mm (L) x 7.62mm to 22.86mm (W), depending on the number of positions. E-Switch KAD Multiple Position DIP Switches provide 0.8mm travel in each direction and have gold contacts with an operating temperature of -20°C to +85°C and storage temperature of -40°C to +85°C. The KAD DIP switch series allows users to quickly preconfigure an electronic device between various settings or operating modes for such applications as audio-visual, computer peripherals, consumer electronics, medical equipment, telecommunications, and testing and instrumentation.　　FEATURES　　Tri-state DIP switch　　Straight pins (Through Hole), or gullwing (SMT) termination options　　Tube or Tape & Reel packaging options　　Top tape seal option with recessed actuator　　3.70mm (H) x 7.00mm (L) x 7.62mm to 22.86mm (W) profile　　4, 5, 8, 9, or 10 positions　　Gold contacts　　Switches are supplied with all poles in “OFF” position　　APPLICATIONS　　Audio-visual　　Computer peripherals　　Consumer electronics　　Medical equipment　　Telecommunications　　Testing and instrumentation　　SPECIFICATIONS　　Electrical rating:　　100mA @ 50VDC non-switching　　25mA @ 24VDC switching　　2000 cycles for each circuit　　100mΩ (max.) contact resistance　　100 MΩ min. at 500VDC insulation resistance　　500VAC for 1 min. dielectric strength　　-20°C to +85°C operating temperature　　-40°C to +85°C storage temperature　　0.8mm travel in each direction　　SPDT contact arrangement in each position

Key word：

E-Switch

Release time：2023-04-03 11:20 reading：3678 Continue reading>>

Trade news

Ameya360:Panasonic EVP-BD 6mm 4N Square Tactile Switch

　　Panasonic EVP-BD 6mm Square Tactile Switch offers an operating force of 4N with 0.7mm travel distance and 200,000 cycles of operation. This switch features a metal dome and rubber dome construction for a sharp tactile feeling with silent operation. The high operating force and long travel distance reduce the chance of unintentional activation. This top-push SMD switch has two J-bent terminals and 6mm x 6mm external dimensions with a 4mm height. Panasonic EVP-BD 6mm Square Tactile Switch ensures operational safety for applications such as audio electronics and automotive equipment. Additional applications include consumer, medical, industrial, and lighting.　　FEATURES　　SMD mounting type　　Snap-action / push-on type SPST　　Top push　　Middle stroke travel　　High click ratio of operating force vs. travel distance offers crisp tactile feel　　Rubber dome provides quiet operation　　High endurance　　High operating force and long travel distance for lower chance of unintentional activation　　J-bent terminal　　With push plate (actuator)　　Reflow applicable soldering　　APPLICATIONS　　Automotive　　Industrial　　Consumer　　Medical　　Audio　　Lighting　　SPECIFICATIONS　　4N operating force　　0.7mm travel　　6mm x 6mm external dimensions　　4mm height　　10ms maximum bouncing (ON, OFF)　　200,000 cycles operating life　　10μA 2VDC to 20mA 15VDC (resistive load) rating　　500MΩ maximum contact resistance　　100MΩ minimum insulation resistance at 100VDC　　250VAC (1 minute) dielectric withstanding voltage　　-40°C to +90°C operating temperature range

Key word：

Ameya360,Panasonic

Release time：2023-02-27 11:44 reading：1819 Continue reading>>

Trade news

Diodes’ Power Switch Enhances Power-rail Management in SSDs

　　Diodes' new single-channel high-side power switch features three different selectable slew rates so that wider capacitance loads can be handled while keeping inrush currents down.　　Diodes Inc. has launched a new versatile single-channel high-side power switch that features three different selectable slew rates so that wider capacitance loads can be handled while keeping inrush currents down, ensuring system stability. The DIODES AP22980 power switch is targeted at the solid-state data storage systems used in portable electronic equipment, computer hardware, and edge-based data center deployments.　　The N-channel MOSFET, with a built-in charge pump inside the AP22980, has an extremely low Rds(ON) of 5.1m? enabling loads reaching 6A while minimizing voltage drops and power losses in high current loading applications. By having a separate VBIAS pin, the minimum input voltage that it is capable of supporting is significantly lower, resulting in a wider input voltage range that can be covered—from 0.285V to 5.5V—enabling greater application flexibility.　　With 60?A (typical) quiescent supply current, the AP22980 is highly optimized for situations where keeping standby power consumption down is a priority. This device has an operational temperature range of -40°C to 105°C. If the junction temperature exceeds 150°C, an overtemperature protection mechanism is triggered.　　The AP22980 three-level selectable slew rate power switches are supplied in the compact W-QFN1520 package that takes up little board space and eases integration.

Key word：

Diodes

Release time：2022-12-27 13:27 reading：2177 Continue reading>>

Trade news

Scientists integrate opitcal components into chips designs

A group of researchers from MIT, the University of California at Berkeley and Boston University have developed a technique for assembling on-chip optics and electronic separately, which enables the use of more modern transistor technologies.The technique can be used by existing manufacturing processes and according to Amir Atabaki, one of the research scientists involved in the project, "The most promising thing about this work is that you can optimise your photonics independently from your electronics."Moving from electrical communication to optical communication is an attractive proposition for chip manufacturers because it could significantly increase chips' speed and reduce power consumption, an increasingly important advantage as chips' transistor count continues to rise:The integration of optical - or "photonic" - and electronic components on the same chip reduces power consumption. The optical communications devices currently on the market tend to consume too much power and generate too much heat to be integrated into an electronic chip such as a microprocessor.Atabaki and his colleagues have used a more space-efficient modulator design, based on a photonic device called a ring resonator."We have access to photonic architectures that you can't normally use without integrated electronics," Atabaki explains. "For example, today there is no commercial optical transceiver that uses optical resonators, because you need considerable electronics capability to control and stabilize that resonator."In addition to millions of transistors for executing computations, the researchers' new chip includes all the components necessary for optical communication: modulators; waveguides, which steer light across the chip; resonators, which separate out different wavelengths of light, each of which can carry different data; and photodetectors, which translate incoming light signals back into electrical signals.Silicon must be fabricated on top of a layer of glass to yield useful optical components. The difference between the refractive indices of the silicon and the glass is what confines light to the silicon optical components.Earlier work on integrated photonics involved a process called wafer bonding, in which a single, large crystal of silicon is fused to a layer of glass deposited atop a separate chip. The new work, in enabling the direct deposition of silicon on top of glass, uses polysilicon, which consists of many small crystals of silicon.Single-crystal silicon is useful for both optics and electronics, but in polysilicon, there's a trade-off between optical and electrical efficiency. Large-crystal polysilicon is efficient at conducting electricity, but the large crystals tend to scatter light, lowering the optical efficiency. Small-crystal polysilicon scatters light less, but it's not as good a conductor.Using the manufacturing facilities at SUNY-Albany's Colleges for Nanoscale Sciences and Engineering, the researchers tried out a series of recipes for polysilicon deposition, varying the type of raw silicon used, processing temperatures and times, until they found one that offered a good trade-off between electronic and optical properties."I think we must have gone through more than 50 silicon wafers before finding a material that was just right," Atabaki said.

Key word：

chips designs

Release time：2018-04-23 00:00 reading：1273 Continue reading>>
